Tapping Terminal Block Al/Cu UK50/2A, 1P (4holes) 2.5-50mm² 145/160A, 6pcs/pck, TS35, grey Code:
1914105
|
|
Gross price: €4.00 /pc
|
Weight:
0.05 kg
Volume:
0.0001 m3
Availability:
In Stock
|
|
Terminal Block Al/Cu 2x(2,5-50mm²), grey
 |
|
| Name |
Terminal Block Al 6-50 mm², Cu 2.5-50 mm², grey |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Colour: |
grey |
| Wire mm²: |
Cu 2,5-50 mm² Al 6-50 mm² |
| Nominal Insulation Voltage V: |
800 V |
| Screw head size: |
5 mm |
| Nominal Rated Current A: |
Cu 300 A, Al 240 A |
| Number of poles: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Nominal Tightening Torque Nm: |
4 Nm (2.5-4mm²), 12 Nm (6-50mm²) |
|
|
|
