Tapping Terminal Block Al/Cu UK150/2N, 1P (4holes) 35-150mm² 290/320A, TS35 ˄panel mount, blue Code:
1914126
|
|
Gross price: €10.80 /pc
|
Weight:
0.17 kg
Volume:
0.0002 m3
Availability:
In Stock
|
|
Terminal Block Al/Cu 2x25-150mm², blue
 |
|
| Nimi |
Klemm Al/Cu 2x(25-150mm²), sinine |
| Töötemperatuur (ºC): |
max 80ºC |
| Korpus: |
polüamiid |
| Kinnitus: |
DIN-liist |
| Poldipea: |
kuuskant
|
| Värv: |
hall |
| Juhtme ristlõige mm²: |
35-150 mm² |
| Isolatsiooni nimipinge V: |
800 V |
| Kruvipea suurus: |
8 mm |
| Maksimumpinge V: |
600V |
| Nimivool A: |
Cu 570 A, Al 460 A |
| Pooluste arv: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Pingutusmoment Nm: |
14 Nm (35-95mm²), 24 Nm (120-150mm²) |
|
|
|
