Tapping Terminal Block Al/Cu UK240/2PE, 1P (4holes) 35-240mm² 380/425A, TS35 ˄panel mount, yegr Code:
1914137
|
|
Weight:
0.35 kg
Volume:
0.0004 m3
Availability:
In Stock
|
|
Terminal Block Al/Cu 35-240mm², yegr
 |
|
| Name: |
Terminal Block Al/Cu 35-240mm², yegr |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
screw |
| Screw head: |
hexagon
|
| Colour: |
yegr |
| Wire mm²: |
35-240 mm² |
| Nominal Insulation Voltage V: |
800 V |
| Screw head size: |
8 mm |
| Nominal Rated Current A: |
Cu 760 A, Al 620 A |
| Number of poles: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Nominal Tightening Torque Nm: |
102 Nm (35-70mm²), 45 Nm (95-240mm²) |
|
|
|
